Electro Galvanized Wire

This method does not use a molten zinc bath. Instead, it involves applying zinc in a thin coating to the base metal, typically through an electroplating process. The zinc coating applied by electro-galvanizing is smoother than that of hot-dip galvanized products.

  • Product Details

Electro Galvanized Wire Description

Name Electro Galvanized Wire
Standard GB/ASTM/SAE/AISI/DIN/JIS/EN/BS
Surface Treatment Black/Peeling/Polished/Machined
Delivery Condition Hot Rolled or Forged/Peeled or Black Surface
Test SGS/UT 100% Elements Testing
Certificate ISO/Mill Certificate
Service 24 hours online service
More than 20 years trading and manufacture
Quality Assurance The third party inspection, such as SGS, BV, TUV…etc. is acceptable
Packaging Details Seaworthy Packaging or as per customer's packing instruction



Scope of Application

Galvanized steel wire is prevalent across industries and applications. The zinc coating makes galvanized wire useful in many instances where wet conditions or fire hazards make other types of wire unusable. Here are a few of the top applications of galvanized wire.


● Fencing: Galvanized wire's rust and damage resistance is excellent for all kinds of fencing. Galvanized wire is also durable, holding up under high pressure. You can find galvanized wire fencing everywhere, from agriculture fencing to the Hexanet fencing used in insulating buildings.


● Binding: Businesses frequently use galvanized wire to bind or bale construction and recycling materials into one unit. In construction applications, this wire makes it easier for construction teams to work with the materials on the job site. Many companies use galvanized wire to bind other scrap and raw materials.


● Nails and staples: Construction teams need durable materials at every stage of the building process. The strength of these wires makes them ideal for providing buildings and homes with structural support. Galvanized steel wire creates sturdy nails, springs, staples and other structural elements that can withstand heavy strain.


● Consumer goods: Manufacturers have found many uses for galvanized wire in consumer goods applications. From bucket handles to hanging support for artwork and mirrors, galvanized wire offers strength.



Nominal Diameter

(mm)

Tensile Strength Zinc Coating Standard (According to US ASTM A641)
Class A Class 3 Class 4
Tolerance Zinc Coating Tolerance Zinc Coating Tolerance Zinc Coating
1,2 450 – 600
±0,05
40 – 100 ±0,05 214 ±0,05 336
2,0 450 – 600 40 – 100 229 336
2,2 450 – 600 40 – 100 244 336
2,5 450 – 600 ±0,05 40 – 100 ±0,05 244 ±0,05 336
3,2 450 – 600 40 – 100 259 336
3,4 450 – 600 40 – 100 259 336
4,0 450 – 600 40 – 100 275 336
4,2 450 – 600 40 – 100 275 336
4,5 450 – 600 40 – 100 275 336
